PASSION™ ED 8x42mm model provides big-time performance in a compact, lightweight package. Ideal for all outdoor enthusiasts.
PASSION™ ED 8x42mm model provides big-time performance in a compact, lightweight package. Ideal for all outdoor enthusiasts. Prism type . Schmidt-Pechan Magnification . 8x Field of view (FOV) at 1.000y . 428 Field of view (FOV) at 1.000m . 143 Objective diameter (mm) Effective diameter 42 Ocular diameter (mm) Effective diameter 23,7 Exit pupil diameter (mm) Measurement of the pupilary ocular beam 5,25 Eye Relief (inches) From the last optical surface 0,7 Eye Relief (mm) From the last optical surface 18 Housing Main body and hinge magnesium Close focus (feet) Shortest focal distance 5,9 Close focus (meters) Shortest focal distance 1,8 Inter pupilary distance (IPD) Center pupil to center pupil measurement 56 – 75 Dioptric compensation range . -2,5/+2,5 Waterproof Mbars 100 Transmission Daylight ISO 14490-5:2005 90% Height (inches) Without covers 2,26 Height (mm) Without covers 55 Weight (ounces) Without covers 26,1 Weight (grams) Without covers 740 Lentgh (inches) At outside diameter 5,4 Lentgh (mm) At outside diameter 138 Width (inches) Fully extended 5 Width (mm) Fully extended 127 Accessories included with the purchase . instruction manual, cleaning cloth, hard case, neoprene neck strap, hard case strap, objective covers, ocular covers
